Satin Nickel 1/2-Inch Thermostatic Shower Control With Diverter

A Satin Nickel 1/2-inch thermostatic shower trim brings temperature memory and diverter control to a coordinated shower-wall installation.

This Satin Nickel shower trim combines thermostatic temperature control with a diverter and temperature memory. The source lists brass construction, 8.5 in H x 4 in W x 3 in D overall dimensions, and a 4 lb. product weight. Compatibility is listed with four separate rough-in valve configurations, each rated at 6.5 GPM / 24.6 LPM. Zero valves are included, so confirm the selected rough-in valve, finished-wall opening, connections, and control arrangement before installation.

• Finish and Material

  This thermostatic shower trim with diverter has a Satin Nickel finish and brass construction.

• Installation Planning

  Installation is required. Plan this visible trim around a compatible rough-in valve behind the finished wall, and confirm the valve location, finished opening, plumbing connections, and control access before the wall is closed.

• Fit and Rough-In

  The source lists overall dimensions of 8.5 in H x 4 in W x 3 in D and names four compatible rough-in options: R1051BV, R1052BD, R1053BD, and R1055BD. Wall depth and connection dimensions are not published in the harvest, so confirm the selected valve and rough-in with your installer.

• Controls and Temperature

  The thermostatic control provides set-and-forget temperature memory. Depending on the compatible rough-in valve, the top handle controls on/off and volume or diverts water between two or three ways, while the bottom handle sets temperature.

• Water Flow

  The source lists 6.5 GPM / 24.6 LPM with the compatible rough-in valve configurations. Treat that as the listed valve-system rating rather than a standalone trim flow promise, and verify the selected valve and household requirements before installation.

• Care

  The source does not publish a detailed cleaning schedule. Follow the manufacturer's current care guidance and use a soft, non-abrasive cloth on the visible finish.

• What Ships

  The source lists zero valves included and does not provide an itemized box-contents list. This listing is for the visible thermostatic trim and diverter controls; confirm any required rough-in valve and installation hardware before ordering.

• Warranty Check

  The source lists a product warranty with limited coverage for a lifetime and no commercial warranty. Review the current warranty terms and installation requirements, and confirm the complete valve-and-trim setup with a qualified plumber.

Good to know

• Overall size: 8.5 in H x 4 in W x 3 in D.
• Confirm R1051BV, R1052BD, R1053BD, or R1055BD compatibility before ordering.
• Zero valves included; verify wall depth, connections, and installation hardware with your plumber.
• Installation is required. Confirm the compatible rough-in valve, finished-wall opening, wall depth, connections, control access, and installation documents before work begins, using a qualified plumber when appropriate.
• Thermostatic shower trim only. Rough-in valve(s), shower components, and other items not explicitly listed are not included.
