Belfield M-CORE 3-Series 1-Handle Eco-Performance Shower Trim Kit, Valve Required in Polished Nickel

$349.99 $449.36 You save $99.37 (22%) Sale

In stock

Key features

See all specifications
  • Material: Metal
  • Finish: Polished Nickel
  • Pieces Included: Shower Head, Handle(s)
  • Mounting / Installation: Wall

Free ground shipping · Typically 1–3 business days after dispatch

Carbon-neutral shipping on all orders

Key features

See all specifications
  • Material: Metal
  • Finish: Polished Nickel
  • Pieces Included: Shower Head, Handle(s)
  • Mounting / Installation: Wall
Free ground shippingFree ground shipping when back in stock Typically 1–3 business days after dispatch
Order within calculating… for the next dispatch
Free returns within 30 days Not loving it? We offer returns on all our products within 30 days of delivery for a refund or store credit.
Details

The Moen Belfield M-CORE 3-Series 1-Handle Eco-Performance Shower Trim Kit comes in Polished Nickel. It pairs a single lever handle with one fixed shower head on a wall mount, with a built-in slide bar.

The volume control lets you adjust the flow of water, up to 1.75 GPM. M-core valves with 3-Series trim have pressure-balancing capabilities designed to control temperature fluctuations when water pressure changes in the home. The trim requires M-core Mixing Valve U140, a separate product. The shower head is 7.13″ wide.

  • Finish and material

    This trim is finished in Polished Nickel and built of metal. The m-core line is designed with perfectly matching mixing and transfer trim, so a shower can carry one look.

  • Controls and temperature

    A single lever handle runs the trim. M-core valves with 3-Series trim have pressure-balancing capabilities designed to control temperature fluctuations when water pressure changes in the home.

  • Water flow

    Volume control lets you adjust the flow of water, and adjustable water flow is built in. Max flow rate is up to 1.75 GPM, delivered in a Full/Standard spray pattern.

  • Fit and compatibility

    This trim kit requires M-core Mixing Valve U140 to complete installation, and the required valve type is Pressure Balanced. The valve is a separate product, so confirm it with your installer before ordering.

  • Installation

    The trim mounts to the wall. The M-core valve has an integrated mounting bracket that secures it directly to a brace, and an integrated test cap lets installers flush and test the system without removing the cartridge.

  • Shower head and slide bar

    The kit has one fixed shower head, 7.13″ wide, with a built-in slide bar. The spray pattern is Full/Standard, and the head is the only one in this kit.

  • What ships

    Pieces included are a shower head and handle(s), with one handle in the kit. The M-core valve it requires is a separate product. Overall product weight is 4.47 lb.

Good to know

  • Requires M-core Mixing Valve U140
  • Required valve type: Pressure Balanced
  • Wall mounting
  • The valve is a separate product
Specifications
Product Type
shower
Max Flow Rate
1.75 GPM
Spray Pattern
Full/Standard
Required Valve Type
Pressure Balanced
Number of Shower Heads
1
Handle Style
Lever
Shower Head Type
Fixed Shower Head
Pieces Included
Shower Head, Handle(s)
Number of Handles
1
Number of Faucet Handles
Single
Material
Metal
Built-In Features
Slide Bar, Adjustable Water Flow
Mounting / Installation
Wall
Finish
Polished Nickel
Shower Head
7.13'' W
Overall Product Weight
4.47 lb.
Assembly
Wall mounting. The trim requires M-core Mixing Valve U140, a separate product. That valve has an integrated mounting bracket that secures it directly to a brace.
